Lavatrice Hi Sense

Samsung H76L

Samsung H76L Washing Machine

Tap the photo to view it in full screen

WFGA8014V.pdf PDF · 12,2 MB · 26 pages

Wiring diagrams, CAD drawings, exploded parts and technical data sheets of the product.

Washing Machine Motor 12542001214 WEBP · 12,8 KB · 1 page
Door PNG · 972,1 KB · 1 page
Electronic Board JPG · 212,8 KB · 1 page

General

Width
600 mm
Height
850 mm
Depth
430 mm
Depth with door closed
462 mm
Depth with door open
947 mm

Dimensions

Maximum load
See the information label
Depth with door open
947 mm
Depth with door closed
462 mm

Electrical

Current
16 A
Frequency
50 Hz
Rated power
2200W
Rated voltage
220-240 V ~
Water pressure
0.05-0.8 MPa (0.5 - 8 bar)
Water leak
Check if the filter door is closed.
How do I start the washing machine?
Connect the washing machine to the power supply and water. Press the POWER button and select the wash program.
What does the light on the pump filter mean?
If the symbol lights up, it means the pump filter needs to be cleaned.
How do I clean the detergent drawer?
Remove the drawer and clean it with warm water and a cloth. Ensure there are no detergent residues.
How often should I clean the pump filter?
The pump filter should be cleaned whenever the corresponding symbol appears on the display.
What should I do if the washing machine doesn't work?
Check if it is connected to the power supply and water. If the problem persists, consult the fault and error table.
How do I change a wash program in progress?
Press the START/PAUSE button to pause the program, then select a new program and press START/PAUSE again.
How do I clean the exterior of the washing machine?
Clean the exterior of the washing machine with a damp cloth and a mild detergent.
What should I do if the water level exceeds normal?
The overflow protection activates, stopping the program and draining the water. Contact support.
